2022 Built 5000 DWT Landing Craft Tank

Ship Particulars

Ship Name: N/A
Port of Registry: Taizhou City, China
Ship No: LC-0425
Classification Society: ZC
Navigation Area: A1 + A2
Type: Landing Craft Tank
Crew: 10

Dimensions

Overall Length: 106.26M
Length × Breadth × Depth: 100.60M × 20.50M × 5.80M
Full Loaded Waterline Length: 102.10M
Draft (Light/Load): 4.024M / 4.220M

Capacity

Cargo Capacity: 4992T
Displacement (Light/Load): 1650.100T / 6817.300T
GRT / NRT: 2996T / 1677T

Engine & Performance

Main Engine: WeiChai CW6250ZLC-1
Power: 2 × 1103kW @ 750 rpm
Engine Build Date: Nov 2021
Oil Consumption: 5T/D
Average Speed: 8 Knots

Generators

Generators:
2 × 250kW @ 1500 rpm
1 × 75kW @ 1500 rpm
1 × 50kW @ 1500 rpm

Survey Information

Date of Completion: Sep 21, 2022
Last Docking Survey: Sep 21, 2022
Next Dry Dock: Sep 20, 2027
